Product Details
＋
NO OBSTACLE IS TOO GREAT
-
OPTIMAL SUSPENSION PERFORMANCE IN ANY SITUATION
The F.O.L.D. chassis, which has been specially designed to meet the demands of Enduro riding, provides a perfectly balanced mix: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.
-
LIGHTWEIGHT, ROBUST AND LOW-MAINTENANCE
High-quality bearings, closed triangle chainstay and a damper protected from dirt – we leave nothing to chance. We have also given thought to the bottle holder.
-
A FAVOURITE AMONG OUR FOCUS TRAIL TEAM
The FOCUS SAM geometry is optimised for use in the diverse Enduro discipline. Alpine terrain, demanding trails, bike park, Enduro races, the SAM is perfectly equipped to handle them all.
SPECIFICATION
FRAME
Carbon front and alloy rear triangle, 170mm F.O.L.D. kinematic, ISCG 05, PF30 BB, 148x12 thru axle, internal cable routing, Post Mount 180 mm
FRAME MATERIAL
Carbon
FORK
FOX 36 Float Rhythm, sweep adjust, 110x15 mm QR, 170mm travel
TRAVEL FORK
170 mm
SHOCK
FOX Float DPX2 Performance, 3-position lever, 230/65 mm, hardware: 30,0 x 8 mm, custom tune
SHIFTER
SRAM GX Eagle
REAR DERAILLEUR
SRAM GX Eagle, 12-speed
SPROCKET
SRAM PG-1230 Eagle, 12-speed
CHAIN
SRAM NX Eagle
CRANKSET
Truvativ Descendant 6K DUB, 32T
TRANSMISSION OF DRIVE
front: 32, rear: 10-50
BOTTOM BRACKET
Shimano Pressfit MTB BB92
HANDLEBAR
BBB, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9 degree
GRIPS
Race Face Grippler
STEM
BBB, aluminium, 55 mm
HEADSET
Acros AIX-322, tapered, IS 42/286-IS52/40
SADDLE
FOCUS Trail Saddle
SEATPOST
KindShock E30i, 31,6mm, internal
BRAKES
SRAM Guide R, 200 mm / 180 mm
BRAKE LEVER
SRAM Guide R
BRAKE
Disc
WHEELSET
DT-Swiss E1900, 584-25, 15x110 MM / 12x148 MM
TIRES
Maxxis HighRoller II 2.5 3C EXO TR
REAR TIRE
Maxxis DHF 2.5 3C EXO TR
GEARS
12
BIKE WEIGHT INCL. BATTERY IN KG.
12345 kg
SIZE
44,41,46
* Subject to technical modification without notice. Errors and omissions excepted.** Weight in size M, of standard specification and without pedals.
